The ASM MS100 Plus is a pre-owned semiconductor test handler used for automated device handling and integration with compatible testing or inspection processes. Its actual loading method, product tooling, test interface, output arrangement and installed functions depend on the specific machine available.
Are you considering the MS100 Plus as a replacement for an existing handler? Send your current machine model, a clear product or package photo and a short description of your requirement. We can review the basic information first and continue with detailed matching only when necessary.
ASM MS100 Plus Machine Information
| Manufacturer | ASM |
|---|---|
| Model | MS100 Plus |
| Equipment Type | Semiconductor test handler |
| Application | Automated device handling and connection with compatible test or inspection processes |
| Condition | Pre-owned semiconductor equipment |
| Product Compatibility | Determined by the installed tooling and handling configuration |
| Actual Configuration | Confirmed according to the specific machine available |
| Delivery Scope | Based on the quotation and confirmed equipment list |
| Support | Initial fault review, replacement-part matching and repair discussion |
| Shipping | Export packing and worldwide delivery |
Could the MS100 Plus Work with Your Product
The availability of an MS100 Plus does not automatically mean that it can handle every semiconductor product. A used machine may have been configured for a particular package, test process or production line.
For the first inquiry, simply send:
Your current machine model, if this equipment will be used as a replacement
The product or semiconductor package name
A clear product, package or existing-tooling photo
A brief explanation of the handling, testing or equipment problem you want to solve
After reviewing the basic requirement, we can continue checking the available machine and ask for additional tooling or interface information only when it is relevant.
What Is Included with the Available Machine
The loading system, handling components, product tooling, test interface and output arrangement may differ between individual MS100 Plus machines. The actual installed configuration should therefore be confirmed from the specific unit being offered.
Only the equipment, tooling, cables and accessories listed in the quotation or confirmed delivery list are included. An external tester, contactor, load board, special tooling, computer or other production-line equipment should not be assumed to be included unless specifically stated.
What Should You Check When the Machine Arrives
Complete a basic receiving inspection before installation or power-on.
Inspect the packing, machine cabinet, control panel, connectors and visible handling mechanisms.
Photograph any impact marks, loose parts, damaged cables or displaced assemblies before moving the machine.
Compare the received machine, tooling and accessories with the confirmed delivery list.
Confirm the electrical supply, grounding and other utility requirements of the actual machine.
Position and level the equipment before operating its loading or transfer mechanisms.
Transport damage or missing items should be recorded before the machine is installed, modified or powered on.
Does the MS100 Plus Start and Cycle Normally
The first startup should confirm that the machine can initialize and complete its basic operating sequence before valuable semiconductor products are introduced.
Start the controller and record any alarm messages before resetting the system or changing parameters.
Confirm that the machine completes initialization and returns its mechanisms to the correct home positions.
Run an empty cycle without loading production products.
Observe the loading mechanism, transfer movement, sensors, test-position movement and output actions.
Stop the test if repeated alarms, mechanical interference, abnormal noise or unstable movement occurs.
Any abnormal operation should be reviewed before sample products are loaded.
Can It Handle and Test Your Products Correctly
After the empty cycle is stable, use suitable samples or non-production products that correspond to the installed tooling.
Check whether the product enters the machine correctly and remains in the required orientation.
Observe pickup, transfer, positioning and release through the handling sequence.
Confirm that the product reaches the intended test, inspection or output position.
If external test equipment is connected, check the interface signals and result handling.
Inspect the samples for scratches, terminal damage, impact marks or unstable contact.
Repeat several complete cycles to identify intermittent sensor, movement or handling problems.
One successful cycle is not enough to confirm production readiness. The complete handling and testing sequence should remain stable without recurring alarms, jams, product damage or incorrect output.
What If the Machine Shows an Alarm or Handles Products Incorrectly
Misfeeds, positioning errors, dropped products, unstable contact or repeated jams may be related to the tooling, sensors, pickup mechanism, motors, pneumatic components, test interface, controller or machine settings.
Stop operation if products are being damaged, mechanisms interfere with each other or the same alarm repeatedly returns. Record the alarm code, operating stage and visible symptoms before resetting the machine.
Photos of the alarm screen, product position, tooling and affected mechanism are useful for an initial review. A short video of the failed operating cycle can also help identify intermittent problems.
Repair and ASM MS100 Plus Parts Support
If the MS100 Plus develops startup alarms, loading problems, unstable transfer, sensor faults, test-position errors or output problems, contact us with the machine information and a brief description of the issue.
Our team can assist with an initial fault review, help identify components that may require inspection and check related electronic or mechanical replacement parts where available.
Support may involve motors, drivers, boards, sensors, cables, pneumatic parts, vacuum components, tooling or other handling assemblies. The appropriate next step depends on the actual fault, machine condition and available information.
Frequently Asked Questions
Can the ASM MS100 Plus handle our semiconductor product?
This depends on the product and the tooling installed on the available machine. Send your current machine model and a clear product or package photo for an initial review.
What tooling and accessories are included?
Only the tooling, cables and accessories listed in the quotation or confirmed delivery list are included.
Does the machine include an external tester?
Not necessarily. External test or inspection equipment is included only when it is specifically listed in the confirmed delivery scope.
Can you assist if the machine has an alarm or requires repair?
Yes. Send the machine model, alarm information, affected-area photos and an operating video where available. We can assist with initial fault review, replacement-part matching and repair discussion.
Contact Us About the ASM MS100 Plus
Send your current machine model, a product or package photo and a short description of your requirement or equipment problem. We will review the basic information first and continue with the necessary machine matching, replacement-parts or repair details afterward.
